How to detach and remove the starter on the Acura MDX?

Disconnect the battery's negative terminal. For 2001-2004 Acura and Honda models, unlatch the ATF cooler hose clamp and move the hose. Remove the starter's upper and lower bolts. For 2003-2006 Acura and all Honda models, detach the harness clamp from the starter bracket. For 2007 Acura models, remove the air filter housing, battery, and transaxle dipstick. Disconnect the wires from the starter motor solenoid. For 2003 and later Acura and 2005 and later Honda models, remove the electrical connector and starter cable. Disconnect wiring clips, remove starter bolts, and remove the starter. Installation is the reverse of removal.

Genuine Acura MDX Starter Motor

Starter Ignition

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

16 Starter motors found

View related parts
Acura MDX Motor Assembly Startr
Part Number: 31200-RYE-A71
$551.09 MSRP: $787.05
You Save: $235.96 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Starter
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Starter Motor Assembly
Part Number: 31200-5J2-A52
$1236.23 MSRP: $1765.53
You Save: $529.30 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Replaces: 31200-5J2-A51
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Core Id Starter (428000-4120) (9742809-412) (Reman) (Denso)
Part Number: 06312-RYE-505RM
$340.50 MSRP: $484.03
You Save: $143.53 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Starter, Core Id (428000-4120) (9742809-412) (Reman) (Denso)
- Replaces: 31200-RYE-A01RM
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Starter Motor Assembly
Part Number: 31200-5MR-A01
$610.63 MSRP: $872.08
You Save: $261.45 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Starter Motor Assembly
Part Number: 31200-6S9-A01
$558.15 MSRP: $797.13
You Save: $238.98 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: STARTER MOTOR ASSY.; Starter
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Starter Motor Assembly (Sm-74020) (Mitsuba)
Part Number: 31200-R9S-A02
$1137.35 MSRP: $1624.32
You Save: $486.97 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Starter
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Core Id Starter (428000-6780) (9742809-678) (Reman) (Denso)
Part Number: 06312-RYE-506RM
$283.34 MSRP: $402.40
You Save: $119.06 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Starter, Core Id (428000-6780) (9742809-678) (Reman) (Denso); Starter
- Replaces: 31200-RYE-A71RM
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Reman Starter
Part Number: 06312-RK1-505RM
$297.06 MSRP: $422.00
You Save: $124.94 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Starter, RM; Starter
- Replaces: 31200-RK1-A71RM
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Remanufactured Starter Motor (Sm-44231) (Sm-44247) (Reman) (Cme/Mitsuba)
Part Number: 06312-PGK-515RM
$405.91 MSRP: $577.45
You Save: $171.54 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Starter, Core Id (Sm-44231) (Sm-44247) (Reman) (Cme/Mitsuba); Starter
- Replaces: 06312-PGK-505RM, 31200-PGK-A01RM
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX STARTER MOTOR ASSY.
Part Number: 31200-5MR-A03
$610.63 MSRP: $872.08
You Save: $261.45 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX STARTER MOTOR ASSY.
Part Number: 31200-5MR-A02
$610.63 MSRP: $872.08
You Save: $261.45 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Starter
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Starter Motor Assembly (Du4V1) (Denso)
Part Number: 31200-RYE-A01
$452.53 MSRP: $646.28
You Save: $193.75 (30%)
Product Specifications
- Other Name: Starter
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Starter Motor Assembly
Part Number: 06313-RDJ-305
Product Specifications
- Replaces: 31200-RDJ-A01, 31200-RDJ-A02
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Starter Motor Assembly (Sm-44247) (Mitsuba)
Part Number: 31200-PGK-A02
Product Specifications
- Replaces: 31200-PGK-A01
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Starter Motor Assembly
Part Number: 31200-RK1-A71
$493.65 MSRP: $705.02
You Save: $211.37 (30%)
Product Specifications
- Other Name: Motor Assembly Starter; Starter
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura MDX Motor Assembly Kit
Part Number: 06314-RDJ-305RM
Product Specifications
- Other Name: Kit, Motor Assembly ; Starter; Starter
- Replaces: 06313-RDJ-305RM
- Warranty: This genuine part is guaranteed by Acura's factory warranty.

Acura MDX Starter Motor

The Starter Motor in Acura MDX cars is important in this case because it is applied to convert the electrical energy from the battery into the mechanical energy to crank the engine in order to start the engine. It does so by use of an external solenoid mounted outside which is linked with the battery to activate the starter internally by means of a rotating armature coupled to field coils. When energized, the solenoid brings the starter drive gear to the engagement with the flywheel of the engine enabling the starting of the engine. Electric Starter Motor, including advanced concepts such as gear reduction systems, are applied in Acura MDX models. The role of the solenoid is critical, since not only does it provide Starter Motor power, but also safe engine engagement. In the grand scheme of things, the design and operation of the Acura Starter Motor have developed to improve reliability and performance of the MDX line up.

We provide a broad range of OEM Acura MDX Starter Motor at unbeatable prices on our website. For your OEM parts, You can count on the guaranteed quality, manufacturer's warranty, outstanding customer service, and prompt delivery. We look forward to your visit.

Acura MDX Starter Motor Parts Questions & Experts Answers

Remanufactured Starter Motor (Sm-44231) (Sm-44247) (Reman) (Cme/Mitsuba)
06312-PGK-515RM
Q: How to detach and remove the starter on the Acura MDX?
A:
Disconnect the battery's negative terminal. For 2001-2004 Acura and Honda models, unlatch the ATF cooler hose clamp and move the hose. Remove the starter's upper and lower bolts. For 2003-2006 Acura and all Honda models, detach the harness clamp from the starter bracket. For 2007 Acura models, remove the air filter housing, battery, and transaxle dipstick. Disconnect the wires from the starter motor solenoid. For 2003 and later Acura and 2005 and later Honda models, remove the electrical connector and starter cable. Disconnect wiring clips, remove starter bolts, and remove the starter. Installation is the reverse of removal.
