How Should Engine Mounts Be Checked and Replaced on a DOHC Engine in an Acura Integra?

Engine mounts seldom require attention, but broken or deteriorated mounts should be replaced immediately to prevent damage or wear on the drive line components. To check the mounts, the engine must be raised slightly to remove the weight from them. Begin by raising the vehicle and securely supporting it on jack stands, then position a jack under the engine oil pan with a large wood block between the jack head and the oil pan, carefully raising the engine just enough to relieve the weight on the mounts. Inspect the mount insulators for any cracks, hardening, or separation from the metal center. Check for any relative movement between the mount and the engine or frame using a large screwdriver or pry bar; if movement is detected, lower the engine and tighten the mount fasteners. Applying rubber preservative to the insulators can help slow deterioration. For replacement, disconnect the battery cable from the negative terminal, ensuring you have the correct activation code for the radio if it has an anti-theft system. Raise the vehicle and support it securely on jack stands, then support the engine. Remove the fasteners, raise the engine with the jack, and detach the mount from the frame bracket and engine. Install the new mount, ensuring it is correctly positioned in its bracket, then install and securely tighten the fasteners.

Genuine Acura Integra Engine Mount

Engine Motor Mount

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

66 Engine Mounts found

View related parts
Acura Integra Rear Engine Mount Mt
Part Number: 50810-ST7-000
$215.79 MSRP: $308.18
You Save: $92.39 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Insulator, Rear Engine Mountingrubber (Mt) ; Side Mount; Rear Mount, Side Mount
- Position: Rear
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Front Right Engine Mount
Part Number: 50841-ST0-N10
$114.01 MSRP: $161.03
You Save: $47.02 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Rubber, Right Front Stopper Insulator (Mt); Front Insulator, Side Mount
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Left Front Stopper Insulator Rubber (Mt)
Part Number: 50842-ST0-N10
$114.01 MSRP: $161.03
You Save: $47.02 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Rubber, Left Front Stopper Insulator (Mt); Front Insulator, Side Mount
- Position: Driver Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Engine Mount (Right Front)
Part Number: 50841-SR3-984
$113.52 MSRP: $160.33
You Save: $46.81 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Rubber, Right Front Stopper Insulator (At); Front Insulator, Side Mount
- Position: Passenger Side
- Replaces: 50841-SR0-981, 50841-SR3-983, 50841-SR3-982
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Left Engine Mount
Part Number: 50842-ST0-N81
$126.02 MSRP: $178.00
You Save: $51.98 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Rubber, Left Front Stopper Insulator (At); Front Insulator, Side Mount
- Position: Driver Side
- Replaces: 50842-ST0-N80
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Rear Engine Mounting Rubber Insulator (At)
Part Number: 50810-ST0-980
$216.29 MSRP: $308.90
You Save: $92.61 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Insulator, Rear Engine Mountingrubber (At) ; Side Mount; Rear Mount, Side Mount
- Position: Rear
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Bracket, Engine Side Mounting
Part Number: 11910-5BF-A00
$67.70 MSRP: $94.42
You Save: $26.72 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Side Mount Bracket
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Rubber, Left Front Stopper Insulator (At)
Part Number: 50842-ST0-N80
$126.02 MSRP: $178.00
You Save: $51.98 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Front Insulator
- Position: Driver Side
- Replaced by: 50842-ST0-N81
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Rod, Torque (Lower)
Part Number: 50890-T60-A21
$173.09 MSRP: $244.48
You Save: $71.39 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Strut, Torque Rod
- Position: Lower
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Rod, Torque (Lower)
Part Number: 50890-T20-A11
$40.39 MSRP: $56.33
You Save: $15.94 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Strut, Torque Rod
- Position: Lower
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Rod, Torque (Lower)
Part Number: 50890-3K0-H21
$106.27 MSRP: $150.10
You Save: $43.83 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Strut, Torque Rod
- Position: Lower
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Rubber Assembly
Part Number: 50820-T60-A21
$285.81 MSRP: $408.18
You Save: $122.37 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: RUBBER ASSY.; Front Mount, Side Mount
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Rubber Assembly
Part Number: 50820-3S5-A11
$104.16 MSRP: $146.13
You Save: $41.97 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: RUBBER ASSY.; Front Mount, Side Mount
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Bracket, Torque Rod
Part Number: 50690-TBA-A01
$33.76 MSRP: $47.08
You Save: $13.32 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Mount Bracket
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Bracket, Torque Rod
Part Number: 50690-T20-A10
$19.47 MSRP: $27.15
You Save: $7.68 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Mount Bracket
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Side Engine Mounting Stay
Part Number: 50625-T60-A20
$20.82 MSRP: $29.03
You Save: $8.21 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: STAY; Front Bracket
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Side Engine Mounting Stay
Part Number: 50625-T20-A10
$17.88 MSRP: $24.93
You Save: $7.05 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: STAY; Front Bracket
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Stay, Transmission Mounting
Part Number: 50855-SD2-A00
Product Specifications
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Bracket, Rear Engine Mounting Stopper
Part Number: 50811-SB2-000
Product Specifications
- Other Name: Stopper
- Position: Rear
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
View related parts
Acura Integra Bracket, Transmission Mounting (At)
Part Number: 50825-SR3-980
Product Specifications
- Other Name: Transmission Mount Bracket
- Warranty: This genuine part is guaranteed by Acura's factory warranty.

| Page 1 of 4 |Next >

1-20 of 66 Results

Acura Integra Engine Mount

Acura Integra Engine Mount plays the vital role of locating the powerplant securely while muting shake and noise that would otherwise be transferred to the cabin. Every Acura is based on an Engine Mount assembly that bolts to the motor and the chassis, but Integra models have taken a few different styles over the years. The basic design consists of two metal brackets with a rubber cushion in between, which means that the Acura powertrain can come into a tight fit but will absorb normal vibrations. Later Integra trims adopted hydraulic versions, often called hydromounts, where rubber surrounds a fluid chamber that allows the Engine Mount to swallow harsher pulses without letting the engine wander. The highly advanced is an active Engine Mount that alters stiffness electronically or by vacuum control, being soft at idle for comfort and becoming stiff with increasing rpm to protect against excessive movement. Regardless of which type you have, every Engine Mount can wear out as rubber becomes old, fluid leaks occur, and electronics falter, which brings clunks and harshness that indicate an Engine Mount needs inspection and replacement so an Acura Integra can drive smoothly again.

We provide a broad range of OEM Acura Integra Engine Mount at unbeatable prices on our website. For your OEM parts, You can count on the guaranteed quality, manufacturer's warranty, outstanding customer service, and prompt delivery. We look forward to your visit.

Acura Integra Engine Mount Parts Questions & Experts Answers

Left Front Stopper Insulator Rubber (Mt)
50842-ST0-N10
Q: How Should Engine Mounts Be Checked and Replaced on a DOHC Engine in an Acura Integra?
A:
Engine mounts seldom require attention, but broken or deteriorated mounts should be replaced immediately to prevent damage or wear on the drive line components. To check the mounts, the engine must be raised slightly to remove the weight from them. Begin by raising the vehicle and securely supporting it on jack stands, then position a jack under the engine oil pan with a large wood block between the jack head and the oil pan, carefully raising the engine just enough to relieve the weight on the mounts. Inspect the mount insulators for any cracks, hardening, or separation from the metal center. Check for any relative movement between the mount and the engine or frame using a large screwdriver or pry bar; if movement is detected, lower the engine and tighten the mount fasteners. Applying rubber preservative to the insulators can help slow deterioration. For replacement, disconnect the battery cable from the negative terminal, ensuring you have the correct activation code for the radio if it has an anti-theft system. Raise the vehicle and support it securely on jack stands, then support the engine. Remove the fasteners, raise the engine with the jack, and detach the mount from the frame bracket and engine. Install the new mount, ensuring it is correctly positioned in its bracket, then install and securely tighten the fasteners.
